62GB-56T14-19SN Connector | MIL-DTL-26482 Series I Bayonet Plug
62GB-56T14-19SN is a 19-pin straight plug for aviation. MIL-DTL-26482 compliant with bayonet lock & strain relief. [Click Here! Get a Quick Quote. Response in 15 Min]
999999 in stock
Share:
Product Categories
Request a Quote
Product Overview
The 62GB-56T14-19SN is a high-reliability circular connector from the 62GB Series, designed as a form, fit, and function equivalent to MIL-DTL-26482 Series II connectors. Engineered for harsh-environment applications, this connector is widely used in aerospace, military systems, industrial equipment, transportation, and other demanding environments where secure signal transmission and long-term durability are essential.
This part number designates a shell size 14 connector with a 19-contact insert arrangement in a socket (S) configuration. The 62GB Series features a quick-coupling bayonet locking mechanism for fast and secure mating, environmental sealing to protect against moisture, dust, and contaminants, and rugged aluminum alloy shell construction with corrosion-resistant finishes for reliable performance under vibration, shock, and extreme operating conditions.
Part Number Breakdown
Stock & Availability
In Stock / Factory Lead Time
At AVIA Electronics, we understand that your project timelines depend on component reliability. To support your mission-critical operations, we maintain a proactive inventory strategy specifically optimized for the 62GB-56T14-19SN and our broader range of high-reliability circular connectors.
In-Stock (Ready to Ship): The 62GB-56T14-19SN is available through our supply network for engineering projects, maintenance requirements, and production support. Orders for available stock are processed efficiently and prepared for secure shipment, helping minimize downtime and maintain your project schedules.
Factory Lead Time: For large-volume requirements of the 62GB-56T14-19SN or products requiring scheduled production, we provide accurate, project-specific lead times. Through our established manufacturing partnerships, we help secure reliable supply capacity with transparent order tracking from production to delivery.
Supply Assurance: We prioritize long-term supply stability for our customers. Whether you require scheduled deliveries, production batch support, accessory kitting, or inventory planning for multi-stage projects, our logistics team can coordinate a customized supply solution aligned with your application requirements and delivery milestones.
Multiple shell sizes available
The 62GB-56T14-19SN is part of the versatile MIL-DTL-26482 Series II platform, which is engineered for reliable performance across complex system architectures. We understand that your designs require consistency; therefore, our connector solutions are available in a broad range of shell sizes and insert configurations to ensure an optimal mechanical and electrical fit for every application.
Full Spectrum of Configurations: While the 62GB-56T14-19SN represents a specific configuration, the wider 62GB Series product line is available in multiple shell sizes and contact arrangements. This allows engineers to scale their designs—from compact control interfaces to high-density signal and power connections—without compromising on reliability.
Universal Interface Standards: Connectors within the 62GB Series utilize a standardized bayonet coupling mechanism, ensuring fast and secure mating performance across compatible configurations. This consistency simplifies installation procedures, maintenance operations, and system integration requirements.
Precision Engineering: Regardless of the selected shell size or insert arrangement, each unit is manufactured to stringent military-grade tolerances. Our components undergo rigorous testing for environmental stress, including vibration, shock, moisture resistance, and temperature cycling, ensuring dependable signal integrity throughout demanding operational conditions.
Custom configurations supported
At AVIA Electronics, we recognize that standard components may not always meet the unique demands of your high-performance systems. While the 62GB-56T14-19SN represents a reliable standard configuration, we offer extensive support for custom engineering solutions to ensure our products integrate seamlessly into your specific design architecture.
Bespoke Pin & Insert Arrangements: If your project requires a non-standard contact layout or a specific combination of power and signal contacts, we can support customized insert arrangements while maintaining the proven performance characteristics of the MIL-DTL-26482 Series II platform.
Specialized Plating & Material Options: Beyond standard shell finishes, we support various material and plating options designed to enhance corrosion resistance, environmental durability, EMI performance, or weight optimization for demanding operating environments.
Modified Shell Geometries: For applications with unique installation constraints, we can assist with customized shell solutions, including modified mounting configurations, backshell options, and accessory integration to simplify assembly and improve system reliability.
Turnkey Kitting & Integration: We provide custom kitting services where the 62GB-56T14-19SN can be supplied with application-specific accessories, including protective covers, backshells, cable assemblies, and related components, ready for efficient integration into your production process.
Sample Policy & Flexible Order Support
At AVIA Electronics, we provide premium, high-reliability interconnect solutions. To ensure the performance of the 62GB-56T14-19SN meets your precise engineering requirements, we offer a professional sampling service. We are committed to supporting innovation at every stage of your product lifecycle.
Sample Availability: We provide samples of the 62GB-56T14-19SN for engineering qualification and prototype testing. As these are high-performance military-grade components, a nominal sample fee applies to cover the material cost and individual handling. This ensures that you receive verified, defect-free parts that are representative of your final production batch.
No Minimum Order Quantity (No MOQ): We believe in supporting innovation regardless of scale. Whether you need a single unit for a critical repair or a small pilot batch for system integration, we operate with no minimum order quantity. You have the flexibility to procure exactly what your current phase requires without the burden of overstocking.
Streamlined Fulfillment: Our logistics team treats every sample order with the same rigor as bulk shipments. From the moment your sample request is processed, we ensure secure, industrial-grade packaging and rapid dispatch, helping you maintain your project momentum.
Logistics & Distribution Services
AVIA Electronics utilizes a reliable distribution framework to ensure the secure and accurate delivery of components to global destinations. Shipping options available for your order are calculated and displayed during the checkout process based on your specific requirements.
Supported Carriers & Services
We partner with established logistics providers to offer a range of delivery solutions:
Express Carriers: DHL, UPS, FedEx, SF Express
Postal & Standard Services: Belgium Post, Global Direct Standard Line, Registered Mail
Shipping Cost Calculation
Shipping charges are dynamically calculated at checkout to ensure accuracy. The final cost is determined by the following variables:
Package Weight: The total combined weight of the products and necessary protective packaging.
Service Selection: Costs vary depending on the chosen carrier and the selected service level (e.g., expedited express vs. standard delivery).
Destination: Rates are adjusted based on the specific country or region of delivery.
Technical Specifications
Basic Info.
|
Model NO. |
62GB-56T14-19SN |
|---|---|
|
Application |
Industrial Automation |
|
Contact Material |
Copper |
|
Shell Material |
Aluminum alloy |
|
Shell Size |
14 |
|
Termination Style |
Solder |
|
Contact Plating |
Gold |
|
Transport Package |
Standard Expect Package |
|
Origin |
China |
|
Production Capacity |
100000 |
|
Certification |
ISO 9001, ISO 14001, ISO 45001, CE, RoHS, REACH, IP68, 500-Hour Salt Spray Tested |
|---|---|
|
Contact Resistance |
≤ 12.0(mΩ) |
|
Surface Treatment |
Olive green cadmium plating |
|
Processing and Customization |
OEM/ODM |
|
Shell Style |
Wall Mount Receptacle |
|
Mounting Style |
Wall Mount Receptacle |
|
Mating Style |
Triple-Start Threaded Coupling |
|
Grommet and seal |
Silicon rubber |
|
Endurance |
500 cycles |
|
Trademark |
AVIA |
|
HS Code |
8536901100 |
Packaging & Weight
|
Package Size |
41.00cm * 31.00cm * 30.00cm |
|---|---|
|
Package Gross Weight |
100g |
Mechanical Specifications
Vibration
|
Sine |
60g, with temperature cycling and simulated accessory (36 hours) |
|---|---|
|
Random |
44.1 grms in high temperature 49.5 grms in ambient temperature |
|
Shock |
At 3 ms half sinusoid, peak value of acceleration: 300g |
Contact Retention
|
22D# |
45N |
|---|---|
|
20# |
67N |
|
16# |
111N |
|
12# |
111N |
|
10# |
111N |
|
8 # |
111N |
Electrical Performance
Voltage rating (V)
|
Package Size |
M |
N |
I |
II |
|---|---|---|---|---|
|
Sea level |
1300 |
1000 |
1800 |
2300 |
|
21000M |
800 |
600 |
1000 |
1000 |
Contact resistance and rated current
|
Contact Size |
Diameter (mm) |
Resistance (mΩ) |
Current (A) |
|---|---|---|---|
|
22D# |
Φ 0.76 |
≤ 12.0 |
5.0 |
|
20# |
Φ 1.00 |
≤ 5.0 |
7.5 |
|
16# |
Φ 1.60 |
≤ 2.5 |
13.0 |
|
12# |
Φ 2.40 |
≤ 1.5 |
23.0 |
|
10# |
Φ 3.15 |
≤ 1.0 |
40.0 |
Environmental Performance
Operating temperature
|
W class |
-65 oC ~ +175 oC |
|---|---|
|
K, F class |
-65 oC ~ +200 oC |
Salt spray
|
F class |
48h |
|---|---|
|
W class |
500h |
|
K class |
1000h |
Typical Applications
- Military Communication
- Aerospace Systems
- UAV & Defense Electronics
- Industrial Automation
Cross-Reference & Mating
Compatible Brands & Mating
|
Brands |
Equivalents |
Mates |
|---|---|---|
|
Amphenol |
62GB-56T14-19SN |
62GB-51T14-19PN |
|
Souriau |
- |
- |
|
ITT Cannon |
- |
- |
|
Aero/Conesys |
- |
- |
|
Deutsch |
- |
- |
Compatible Backshells & Caps
|
Type |
Backshells |
Dust Caps |
|---|---|---|
|
Straight, Grommet Nut |
M85049/14-19S |
D38999/33K19N |
|
45°Quick Clamp |
M85049/15-19S |
|
|
90°Quick Clamp |
M85049/16-19S |
|
|
Straight, Spin Coupling Environmental EMI/RFI Backshell |
M85049/18-19S |
|
|
Straight, Spin Coupling Non-Environmental EMI/RFI Backshell |
M85049/19-19S |
|
|
Straight Crimp Ring Adapter |
M85049/20-19S |
|
|
Straight, Spin Coupling Non-Environmental Backshell |
M85049/21-19S |
|
|
Straight Strain Relief Clamp |
M85049/38-19S |
|
|
90°Strain Relief Clamp |
M85049/39-19S |
|
|
45°, Spin Coupling Environmental EMI/RFI Backshell |
M85049/78-19S |
|
|
90°, Spin Coupling Environmental EMI/RFI Backshell |
M85049/79-19S |
|
|
Straight, Spin Coupling, cont. Shrink Boot Adapter |
M85049/69-19S |
|
|
Straight, Self-Lock Band Lock Adapter |
M85049/88-19S |
|
|
45°, Self-Lock Band Lock Adapter |
M85049/89-19S |
|
|
90°, Self-Lock Band Lock Adapter |
M85049/90-19S |
|
|
Straight Pre-Shield Adapter |
M85049/115-19S |
|
|
90°Pre-Shield Adapter |
M85049/117-19S |
|
|
Straight, Strain Relief Clamp |
M85049/124-19S |
|
|
90°Strain Relief Clamp |
M85049/126-19S |
