Прямоугольный гнездовой разъем J14F-27ZJB с 27 контактами
Low-frequency J14F-27ZJB 34-pin rectangular female receptacle. Features quick-release locking and solder termination for aerospace systems. Request a quote.
999999 в наличии
Делиться:
Категории товаров
Запросить сейчас
J14F-27ZJB Authentic Compliance and Interface Geometry
Он J14F-27ZJB is a highly reliable, low-frequency rectangular socket connector produced to meet the rigorous performance requirements of modern aerospace and tactical networks. Featuring 27 precision socket contacts, this female receptacle is built with a specialized structural insert that incorporates an anti-reverse physical alignment system. This design prevents terminal damage and guarantees correct mating when paired with matching 27-pin male plugs.
Основные характеристики
Материал оболочки | Номинальное напряжение | Текущий рейтинг | Рабочая температура | Циклы спаривания |
|---|---|---|---|---|
Алюминиевый сплав | ~800 В переменного тока | 3 А | от -55 °C до +125 °C | >500 |
Mechanical Quick-Locking and Retention
A major technical highlight of this connector variant is its integrated quick-operating locking mechanism. The JB suffix specifies the exact hardware and mounting configuration, allowing technicians to achieve a rapid, secure lock upon mating. This mechanical layout keeps the connected pair firmly in place during intense vibration and continuous physical movement, while still supporting fast manual release for maintenance needs.
Premium Materials and Electrical Shielding
The outer housing is crafted from a high-tensile aluminum alloy and treated with high-grade nickel plating to offer superior mechanical protection and structural durability. This metal construction also serves as a secure barrier against external electrical noise, providing consistent EMI/RFI shielding. This helps maintain signal integrity across the 27 internal circuits when routing sensitive low-voltage data.
Gold-Plated Contacts and Solder Terminal Style
The internal female sockets are precision-machined from a copper alloy and finished with premium gold plating over a nickel underlayer. This high-grade finish prevents surface oxidation and ensures excellent electrical continuity. The rear of the 27 contacts features built-in solder cup terminals, designed for permanent wire welding to create highly reliable, low-resistance connections.
Resilience in Demanding Environments
Built for long-term deployment in harsh settings, this military-grade rectangular receptacle performs consistently across a wide thermal range of -55°C up to +125°C. Its internal dielectric components provide excellent insulation resistance even when exposed to severe temperature cycles, high atmospheric moisture, and low air pressure, making it highly effective for airborne equipment and missile tracking systems.
Часто задаваемые вопросы
Can the J14F-27ZJB mate with matching J14A or J14B connectors?
Can the J14F-27ZJB mate with matching J14A or J14B connectors?
No. The J14F series features unique shell dimensions and a distinct quick-locking system that does not intermate with J14A or J14B models. It must be used with a matching 27-pin J14F series male plug.
What exact mechanical style does the JB hardware suffix represent?
What exact mechanical style does the JB hardware suffix represent?
The JB suffix indicates a specialized quick-locking and mounting assembly, providing a reliable and secure latch for chassis or panel-mount layouts while preventing decoupling from mechanical movement.
What type of wire termination is used for this 27-pin receptacle?
What type of wire termination is used for this 27-pin receptacle?
The J14F-27ZJB features built-in solder cup terminals on the back of the 27 gold-plated socket contacts, allowing for stable, manual wire welding to ensure optimal electrical connection.
What materials are used in the construction of this connector?
What materials are used in the construction of this connector?
It features a lightweight aluminum alloy shell finished with a durable plating, while the 27 internal socket contacts are gold-plated copper alloy for excellent conductivity and corrosion protection.
How can I request 3D CAD files or a localized quote for this part?
How can I request 3D CAD files or a localized quote for this part?
You can request complete engineering drawings, 2D/3D CAD models, and volume pricing details by directly submitting a request to our customer service and technical sales team.
