Y50DX22-05TK2WL2 Circular Connector | Y50DX Series Standards
Y50DX22-05TK2WL2 is a heavy-duty 5-pin circular connector. Size 22 alloy shell with TK2WL2 reinforced environmental sealing. In stock with 15-min quote response.
999999 in stock
Share:
Product Categories
Request a Quote
Y50DX22-05TK2WL2: Tactical Connectivity for High-Load Industrial Grids
In heavy industrial operations, the reliability of a power interface depends on its ability to withstand both mechanical stress and environmental ingress. The Y50DX22-05TK2WL2 is a high-performance 5-pin circular connector housed in a reinforced size 22 alloy shell. This specific model features the TK2WL2 technical specification, providing a ruggedized interface for high-load power and complex signal transmission. As a core component of the Y50DX series standards, it ensures the stability of electrical paths in localized infrastructure where standard hardware may struggle with environmental degradation.
Key Specifications
Shell Material | Voltage Rating | Current Rating | Operating Temp | Ingress Protection | Mating Cycles | Keying & Polarization | Coupling |
|---|---|---|---|---|---|---|---|
Aluminum alloy | ~1000 VAC | ~40 A | -55 °C to +150 °C | IP67 | 500 | N | Quick bayonet coupling |
Technical Performance: The Hardware Engineer’s Perspective
For engineers designing hardware for factory automation, heavy machinery, or localized energy grids, the Y50DX22-05TK2WL2 offers a high-redundancy solution. The size 22 shell architecture provides extensive internal volume for high-performance dielectric materials, ensuring superior insulation resistance even under rapid thermal fluctuations and high-humidity conditions.
Key Technical Highlights:
Model Configuration: Y50DX22-05TK2WL2 (5-Pin arrangement)
Shell Geometry: Size 22 high-strength alloy with tactical anti-corrosion finish
Sealing technology: TK2WL2 enhanced environmental gaskets and cable entry seals
Coupling Style: Rapid bayonet system for secure, vibration-proof mating
Integrity Standards: Engineered for localized climates with extreme dust and moisture
The specialized TK2WL2 enhancement focuses on the mechanical reinforcement of the coupling nut and the integration of a specialized cable strain relief system, ensuring that the 5-pin interface remains protected from external tension and fluid ingress in harsh outdoor sites.
Strategic Sourcing: Global Supply Chain Optimization
Procurement managers looking to replace expensive or long-lead-time traditional military parts can utilize the Y50DX22-05TK2WL2 to maintain project momentum. Adhering to the Y50DX series standards, this connector offers a fully intermateable, high-quality alternative that simplifies the Bill of Materials (BOM) for localized industrial tenders.
Why Procurement Teams Prioritize This Model:
Global Compatibility: Fully intermateable with standard size 22-05 circular sockets across the series
Lead Time Reduction: Maintained in strategic volume for rapid export to industrial hubs in Russia and the Middle East
Response Velocity: Our 15-minute protocol ensures that technical quotes are delivered to your desk immediately
We specialize in managing localized logistics, ensuring that your 5-pin interconnect requirements are met with full documentation and quality assurance reports required for official procurement lists.
Market Value: Insights for Distribution Partners
For regional distributors and global traders, the Y50DX22-05TK2WL2 is a high-value asset for inventory portfolios. Its 5-pin configuration is a versatile standard for three-phase power systems with integrated logic signals, ensuring a broad customer base and consistent re-order potential from industrial end-users.
Distribution Benefits:
Sector Versatility: High demand in telecommunication racks, power cabinets, and robotic nodes
Technical Support Package: We provide CAD models and specification sheets to help your team support localized bids
Logistical Reliability: Proven shipping routes to support localized hardware markets without supply interruptions
FAQ
What is the specific advantage of the TK2WL2 suffix in this series?
What is the specific advantage of the TK2WL2 suffix in this series?
The TK2WL2 designation refers to an enhanced environmental sealing package combined with a reinforced mechanical locking structure, making it ideal for outdoor applications where the connector is subject to both moisture and mechanical pull.
Can the Y50DX22-05TK2WL2 handle 3-phase AC power transmission?
Can the Y50DX22-05TK2WL2 handle 3-phase AC power transmission?
Yes, the 5-pin arrangement is frequently used for 3-phase circuits, providing additional pins for grounding or secondary control signals. Please refer to our datasheet for current limits per pin.
Is the size 22 shell compatible with standard mounting accessories?
Is the size 22 shell compatible with standard mounting accessories?
Yes, it follows standard size 22 physical dimensions, allowing for the use of common backshells, gaskets, and protective caps within the Y50DX series standards.
How does the bayonet coupling perform in high-vibration zones?
How does the bayonet coupling perform in high-vibration zones?
The coupling mechanism provides tactile and audible feedback upon locking, ensuring a gas-tight, vibration-resistant connection that will not decouple under mechanical stress.
How can I request a 1:1 cross-reference for another brand?
How can I request a 1:1 cross-reference for another brand?
Use our 15-minute response chat to provide the competing part number, and our engineers will confirm compatibility and provide a technical comparison instantly.
