J30J-15ZKP | 15-Pin Micro-D Receptacle Connector with Locking Hardware
The J30J-15ZKP is a high-reliability 15-pin Micro-D receptacle connector featuring advanced twist-pin compatibility, durable socket contacts, and integrated locking hardware.
999999 in stock
Share:
Product Categories
Request a Quote
J30J-15ZKP High-Density Reliability for Critical Environments
The J30J-15ZKP is a premium Micro-D receptacle connector designed to maintain continuous data and signal transmission within highly compressed electronic packages. Featuring a 1.27mm contact spacing, this 15-pin interface allows engineering teams to maximize localized pin density without increasing the physical space required for installation. It is widely used in strategic communication systems, drone telemetry hubs, and tactical electronics where saving weight and volume is essential. The compact housing design optimizes signal integrity while keeping thermal generation low across all operational phases.
Key Specifications
Shell Material | Voltage Rating | Current Rating | Operating Temp | Mating Cycles |
|---|---|---|---|---|
Aluminum alloy | ~800 VAC | 3 A | -55 °C to +125 °C | >500 |
Precise Socket Contact and Twist-Pin Integration
As a high-performance receptacle, the J30J-15ZKP incorporates fifteen advanced socket sleeves designed to mate smoothly with the elastomeric twist-pins of matching plugs. This mechanical design creates multiple points of contact within each channel, maintaining continuous electrical connection even when the system faces severe vibration and mechanical shock. The contact sleeves are precision-machined from copper alloy and plated with high-grade gold over nickel. This reduces total contact resistance and prevents oxidation, ensuring dependable performance over long mission durations.
Advanced Termination and Custom Harnessing
To provide maximum assembly flexibility, the backend of the J30J-15ZKP is engineered for direct integration with custom wire harnesses. This allows production technicians to solder application-specific wires directly to the connector terminals, adjusting cable lengths and shielding layers according to the exact layout requirements. The terminal geometry supports reliable solder flow, minimizing the potential for short circuits during assembly. The internal polymer insert keeps the fifteen terminals insulated, preventing current leakage or cross-talk between the active signal lines.
Rugged Aluminum Shell and Locking Hardware
Enclosed within a durable aluminum alloy shell, the J30J-15ZKP delivers excellent structural protection and electromagnetic interference shielding. The metal housing prevents external radio-frequency and electrical noise from disturbing the data streams passing through the connector. The P-type hardware designation confirms the inclusion of specialized locking fasteners. These hardware components allow the receptacle to lock securely into the mating plug, preventing accidental decoupling caused by physical tugging, dynamic vehicle movement, or rapid temperature changes.
Compliance with Stringent Interconnect Standards
The J30J-15ZKP is built in strict accordance with the GJB2446A technical specifications, making it fully compatible with international Micro-D series of the same configuration. This high degree of standard integration ensures that it functions as a drop-in replacement or upgrade within existing high-reliability electronic networks. Its predictable installation footprint and performance metrics eliminate operational risks during the prototyping phase, allowing system developers to deploy reliable equipment in harsh marine, aerospace, and advanced automated industrial setups.
FAQ
What does the 'ZK' code signify in the J30J-15ZKP part number?
What does the 'ZK' code signify in the J30J-15ZKP part number?
The letters ‘ZK’ confirm that the connector is a receptacle (socket type) containing female contacts designed to receive matching male pins.
Does the 'P' in J30J-15ZKP mean it is a PCB mount connector?
Does the 'P' in J30J-15ZKP mean it is a PCB mount connector?
No, in this specific model code, the ‘P’ represents the inclusion of specific locking hardware or fasteners, rather than a PCB straight-pin installation.
What type of contact technology does this connector support?
What type of contact technology does this connector support?
It features high-grade socket contacts designed to mate with the advanced elastomeric twist-pins used in corresponding Micro-D plug connectors.
How are the wires connected to the backend of the J30J-15ZKP?
How are the wires connected to the backend of the J30J-15ZKP?
The backend terminals are designed for direct manual wire termination, allowing technicians to solder custom cables directly to the contacts.
What is the benefit of the gold plating on the 15 pins?
What is the benefit of the gold plating on the 15 pins?
The gold-over-nickel plating offers superior corrosion resistance and keeps electrical contact resistance low, allowing the connector to endure over 500 mating cycles.
